Slim and light-weight
Standard module size of 320x160mm
Standard cabinet size 640*640mm/960*960mm
Very light to move
Thin and light cabinet design is easy for installation and maintenance.
Accurate design and Fast lock
Seamless installation by using accurate die-casting cabinet.
Fast lock and easy maintenance.
High brightness and high Contrast Ratio
High brightness with low power consumption.
High contrast ratio brings excellent performance.
Model name | OF4 | OF5 | OF8 | OF10 |
Pixel Pitch (mm) | 4 mm | 5 mm | 8 mm | 10 mm |
Pixel Density (dot/m2) | 62500 | 40000 | 15625 | 10000 |
LED Type | SMD1921 | SMD2525 | SMD3535 | SMD3535 |
Module Resolution | 80*40 pixel | 64*32 pixel | 40*20poxel | 32*16 pixel |
Module Size (mm * mm) | 320*160 | 320*160 | 320*160 | 320*160 |
Horizontal Viewing Angle (Deg) | 140 | 140 | 140 | 140 |
Vertical Viewing Angle (Deg) | 140 | 140 | 140 | 140 |
Brightness (cd/m2) | 6500 | 6000 | 6000 | 6500 |
Grey Scale(bit) | 14-16bit | 14-16bit | 14-16bit | 14-16bit |
IC Driver | MBI5153 | MBI5153 | MBI5153 | MBI5153 |
Refresh Rate (Hz) | ≥3840 | ≥3840 | ≥3840 | ≥3840 |
Maximum Power Consumption (W/sqm) | 800 | 800 | 850 | 900 |
Average Power Consumption (W/sqm) | 240 | 240 | 280 | 300 |
Cabinet Size 1 (mm*mm) | 640*640 | 640*640 | 640*640 | 640*640 |
Cabinet Size 2(mm*mm) | 960*960 | 960*960 | 960*960 | 960*960 |
Scan | 1/8 Scan | 1/8 Scan | 1/4 Scan | 1/2 Scan |
Angle Adjustment (optional) | optional | optional | optional | optional |
Input Voltage (V) | 110-220V | 110-220V | 110-220V | 110-220V |
Life Span | ≥100.000 hrs | ≥100.000 hrs | ≥100.000 hrs | ≥100.000 hrs |
(MTBF)Min | 10.000 hrs | 10.000 hrs | 10.000 hrs | 10.000 hrs |
Waterproof Level | IP65 | IP65 | IP65 | IP65 |
Working Environment | Outdoor | Outdoor | Outdoor | Outdoor |
